Part A - Position vector from A to B Learning Goal: As shown, two cables connect...
Fantastic news! We've Found the answer you've been seeking!
Question:
Transcribed Image Text:
Part A - Position vector from A to B Learning Goal: As shown, two cables connect three points. C is below A by a distance C = 1.10 ft and connected to A by a cable 6.91 ft long. Cable AC forms an angle = 33.0 with the positive y axis. B is 9.50 ft above C and the distances B, and By are 6.90 ft and 6.10 ft, respectively. ( Figure 1) Using the dimensions in the figure, find the position vector from A to B in component form. Express your answers, separated by commas, to three significant figures. View Available Hint(s) Figure 1 of 1 TAB= Submit 11 vec Part B - Unit direction vector for line AB ? ift, j ft, k ft For the position vector found in Part A, find the unit direction vector acting in the same direction. Express your answer in component form. Express your answers, separated by commas, to three significant figures. View Available Hint(s) 11 vec UAB Submit Part C - Position vector from A to C ? i,j, k The length of cable AC is 6.91 ft, and the cable forms the angle = 33.0 with the y axis. Given this information and the dimensions provided in the figure, find the position vector from A to C. Express the position vector in component form. Express your answers, separated by commas, to three significant figures. View Available Hint(s) vec ? Part D - Position vector from B to C Find the position vector from B to C. Express your answer in component form. Express your answers, separated by commas, to three significant figures. View Available Hint(s) vec IBC Submit Part E - Tension in the cable ? ift, j ft, k ft A cable is attached between B and C. The cable is attached in such a way that it has a tension of TBC along its length. The tensile force will attempt to pull B toward C. The force exerted on B has a z component with a magnitude of 10 lb. What is the magnitude of the tension in the cable, TBC? Express your answer to three significant figures and include the appropriate units. View Available Hint(s) ? Units TBC = Value Submit Part A - Position vector from A to B Learning Goal: As shown, two cables connect three points. C is below A by a distance C = 1.10 ft and connected to A by a cable 6.91 ft long. Cable AC forms an angle = 33.0 with the positive y axis. B is 9.50 ft above C and the distances B, and By are 6.90 ft and 6.10 ft, respectively. ( Figure 1) Using the dimensions in the figure, find the position vector from A to B in component form. Express your answers, separated by commas, to three significant figures. View Available Hint(s) Figure 1 of 1 TAB= Submit 11 vec Part B - Unit direction vector for line AB ? ift, j ft, k ft For the position vector found in Part A, find the unit direction vector acting in the same direction. Express your answer in component form. Express your answers, separated by commas, to three significant figures. View Available Hint(s) 11 vec UAB Submit Part C - Position vector from A to C ? i,j, k The length of cable AC is 6.91 ft, and the cable forms the angle = 33.0 with the y axis. Given this information and the dimensions provided in the figure, find the position vector from A to C. Express the position vector in component form. Express your answers, separated by commas, to three significant figures. View Available Hint(s) vec ? Part D - Position vector from B to C Find the position vector from B to C. Express your answer in component form. Express your answers, separated by commas, to three significant figures. View Available Hint(s) vec IBC Submit Part E - Tension in the cable ? ift, j ft, k ft A cable is attached between B and C. The cable is attached in such a way that it has a tension of TBC along its length. The tensile force will attempt to pull B toward C. The force exerted on B has a z component with a magnitude of 10 lb. What is the magnitude of the tension in the cable, TBC? Express your answer to three significant figures and include the appropriate units. View Available Hint(s) ? Units TBC = Value Submit
Expert Answer:
