Question: 1. Determine the angle 03 and position xB for BOTH configurations of a slider-crank mechanism with these dimensions: 2=6.00 in r3=9.00 in e=1.00 in

1. Determine the angle 03 and position xB for BOTH configurations of

1. Determine the angle 03 and position xB for BOTH configurations of a slider-crank mechanism with these dimensions: 2=6.00 in r3=9.00 in e=1.00 in 02=60.0 degrees 12 A 031- r3 B 02 XB (b) (a)
