Question: 8 . 1 Given: Plates as shown welded with E 7 0 fillet weld Plates A 3 6 ( F y = 3 6 ksi,

8.1 Given: Plates as shown welded with E70 fillet weld
Plates A36(Fy=36ksi,Fu=58ksi )
Find: Ultimate tension load that could be applied.
Pn( yield )=
Pn( fracture )=
Rn( welds )=
Tu=
8 . 1 Given: Plates as shown welded with E 7 0

Step by Step Solution

There are 3 Steps involved in it

1 Expert Approved Answer
Step: 1 Unlock blur-text-image
Question Has Been Solved by an Expert!

Get step-by-step solutions from verified subject matter experts

Step: 2 Unlock
Step: 3 Unlock
