$$ A single$-$suction, kinetic pump transfers a fluid from a source tank to a discharge tank as described in the image and table above. Determine $NPS{H}_A($ ft $).$

$2.$ A single$-$suction, kinetic pump transfers a fluid from a source tank to a discharge tank as described in the image and table above. Determine $NPS{H}_R($ ft $).$

$3.$ A single$-$suction, kinetic pump transfers a fluid from a source tank to a discharge tank as described in the image and table above. Determine if cavitation will occur.

NPSH

$($ft liq

$\backslash$table$[[$Flow rate $($gpm$),10],[$Fluid$,$Water at $100F$
