Question: A ) The turn - table shown above is rotating around the z axis, the hinge attached to it is rotating around the y axis,

A) The turn-table shown above is rotating around the z axis, the hinge attached to it is rotating around the y axis, and the link attached to the hinge is extending along the xaxis. In what directions are the components of vB?(select all that apply)
-x
+y
-y
-z
+x
+z
B) The turn-table shown above is rotating around the xaxis, the hinge attached to it is rotating around the y axis, and the link attached to the hinge is extending along the zaxis. In what directions are the components of vB?(select all that apply)
-y
-x
+y
-z
+z
+x
A ) The turn - table shown above is rotating
