An AC source operating at 50 Hz with a maximum voltage of 166 V is connected in series with a resistor {R = 1.0 k9} and a capacitor [C = 2.5 #F). (a) What is the maximum value of the current in the circuit? :IA (b) What are the maximum values of the potential difference across the resistor and the capacitor? MR, max =: v Ava, max =: V (c) When the current is zero, what are the magnitudes of the potential difference across the resistor, the capacitor, and the AC source? How much charge is on the capacitor at this instant? (d) 1u'Iifhen the current is at a maximumr what are the magnitudes of the potential differences across the resistor, the capacitor, and the AC source? How much charge is on the capacitor at this instant? Consider a series RLC circuit with R = 29 0, L = 6.0 mH, and C = 35 (F. The circuit is connected to a 10-V (rms), 600-Hz AC source. (a) Is the sum of the voltage drops across R, L, and C equal to 10 V (rms)? O Yes O No (b) Which is greatest, the power delivered to the resistor, to the capacitor, or to the inductor? O the power delivered to the resistor O the power delivered to the capacitor O the power delivered to the inductor O The power delivered to each is the same. (c) Find the average power delivered to the circuit. WA sinusoidal voltage 1w 2 [?0.0 V]sin{140r) is applied to a series RLC Circuit with .L = 30.0 mH, C = 140.0 trF, and R = 34.0 [1. (a) What is the impedance of the circuit? :9 (b) What is the maximum current in the circuit? :A
