Question: Consider the beam shown in ( Figure 1 ) . Suppose that w = 1 2 k N m and P = 2 4 k

Consider the beam shown in (Figure 1). Suppose that w=12kNm and P=24kN. Assume EI is constant.
Determine the slope at point A. Use the principle of virtual work.
Express your answer in kilonewtons times meter squared divided by EI to three significant figures. positive value for a clockwise slope and a negative value for a counterclockwise slope.
Submit:
Previous Answers
All attempts used; correct answer displayed
Part B
Determine the displacement at point C. Use the principle of virtual work.
Express your answer in kilonewtons times meter cubed divided by EI to three significant figures. En positive value if the displacement is downward and a negative value if the displacement is upward.
(C)v=238kN*m3EI
Previous Answers
submit
Figure
1 of 1
Provide Feedback
Consider the beam shown in ( Figure 1 ) . Suppose

Step by Step Solution

There are 3 Steps involved in it

1 Expert Approved Answer
Step: 1 Unlock blur-text-image
Question Has Been Solved by an Expert!

Get step-by-step solutions from verified subject matter experts

Step: 2 Unlock
Step: 3 Unlock
