Question: Consider the beam shown in ( Figure 1 ) . Figure 1 of 1 Part B Determine the moment in the beam as a function

Consider the beam shown in (Figure 1).
Figure
1 of 1
Part B
Determine the moment in the beam as a function of x for 0I4ft.
Express your answer in pound-feet in terms of x.
Request Answer
Part C
Determine the shear in the beam as a function of x for x4ft.
Express your answer in pounds in terms ofx.
