**data values are different from the textbook, please don't paste the answer from the textbook**

Consider the topology shown below. Denote the three subnets with hosts (starting clockwise at 12:00) as Networks A, B, and C. Denote the subnets without hosts as Networks D, E, and F. a. Assign network addresses to each of these six subnets, with the following constraints: All addresses must be allocated from 214.97.254/23; Subnet A should have enough addresses to support 120 interfaces; Subnet B should have enough addresses to support 250 interfaces; and Subnet C should have enough addresses to support 120 interfaces. Of course, subnets D, E and F should each be able to support two interfaces. For each subnet, the assignment should take the form a.b.c.d/x or a.b.c.d/x - e.f.g.h/y. b. Using your answer to part (a), provide the forwarding tables (using longest prefix matching) for each of the three routers.

223.1.1.1 223.1.1.4 -223.1.1.3 223.1.9.2 R1 -223.1.7.0 223.1.9.1 223.1.7.1 R2 223.1.8.1 223.1.8.0 R3 -223.1.3.27 223.1.2.6 223.1.2.1 223.1.2.2 223.1.3.1 223.1.3.2
