Direction: Analyze the following process model. Given the parts, and assigned variables and values to activities and paths, answer the following questions:

In answering the questions, copy the questions into the Output Area and

write your answers after each question.

1. Identify the pattern/path of each highlighted part of the process model.

Start from where the trigger is. (0.5 mark each part = 1.5 marks)

2. Determine the equation of each pattern. (1 mark each = 3 marks)

3. Formulate the equation for each pattern according to the labels/variables

assigned. (1 mark for each derived equation = 3 marks)

4. Substitute the values assigned to each variable in each derived equation.

(1 mark for each equation = 3 marks)

5. Calculate for each Average Cycle Time (CT) in the derived equation.

(1 mark for each calculated equation = 3 marks)

6. Calculate for the overall Average Cycle Time (CT). (1.5 marks)
