Question $7,$ Problem $3\mathrm{.}5$a

HW Score: $72\mathrm{.}22\%,13$ of $18$ points

Points: $0$ of $1$

Save

In the following table the activities with their precedence sequence and expected time $($days$)$ are listed for a project on which Carl Betterton's construction company is working:

$\backslash$table$[[$Activity$,$Immediate Predecessor$($s$),$Time $($days$)],[$A$,-,3],[$B$,$A$,4],[$C$,$A$,6],[$D$,$B$,6],[$E$,$B$,4],[$F$,$C$,4],[$G$,$D$,6],[$H$,$E$,$ F$,8]]$

The correct precedence diagram for the project is shown in
