Question: Example 7 . 1 2 : The transfer function of a second - order system is given by: G ( s ) = ( ?

Example 7.12 : The transfer function of a second-order system is given by:
G(s)=(?bar(y))(s)(?bar(f))(s)=1ps2+qs+r
The input variable F(t) is given step change of 8 units, which cause the output y(t) to approach steady-state ultimate response of 0.5 units as shown in Fig. 7.48.
Find the values of p,q and r.
