Question: Example: Plate clutch having a single driving plate with two contact surfaces on each side is required to transmit 1 1 0 kW at 1

Example: Plate clutch having a single driving plate with two contact surfaces on each side is required to transmit 110 kW at 1250 r.p.m. The outer diameter of the contact surfaces is to be 300 mm . The coefficient of friction is 0.4. a. Assuming a uniform pressure of 0.17Nmm2; determine the inner diameter of the friction surfaces.
T=2pf(Ro3-Ri33)
Example: Plate clutch having a single driving
