Exercise $7\mathrm{.}6$: V and M $-$ Integration$/$Areas $-$ Fixed Beam

For the cantilever beam shown in the figure, compute the reactions at the fixed end $A.$ Then draw the shear force and bending moment diagrams $($draw neatly and to the best scale possible, and use the same beam dimension for your diagrams, as below$).$

$15|17||$

AUB$-$MSFEA$-$CFF$.$

CIVE$210-$Statics$-$Problem Sessions

Spring $2022-23$

V & M Dia
