Question: Figure B1.2 Binary Phase Diagram - Copper Nickel System (c) A tie bar 1 metre in length and having a circular cross-section measuring 300mm2 is

Figure B1.2 Binary Phase Diagram - Copper Nickel System (c) A

Figure B1.2 Binary Phase Diagram - Copper Nickel System (c) A tie bar 1 metre in length and having a circular cross-section measuring 300mm2 is required to meet the following design criteria: - Support a maximum tensile load of 90kN - Under maximum load conditions the tie bar must exhibit an extension of less than 4mm Six materials and their associated properties are provided in Table B1. Use this data to determine (i) which materials meet the design criteria (6 marks) (ii) based on performance and cost select the single material that should be used for the tie bar, present the reasons for your choice (5 marks) Table B1 Material properties
