How to solve

In analyzing or designing trusses, it is necessary to determine the force in each member of the truss. One way to do this is the method of joints. The method of joints is based on the fact that if the entire truss is in equilibrium, each joint in the truss must also be in equilibrium $($he$.,$ the free$-$body diagram of each joint must be balanced$).$

Consider the truss shown in the diagram. The applied torces are $P=570lb$ and $P_2=450lb$ and the distance is $d=8\mathrm{.}50ft.$

$($Figure $1)$

Express the magnitudes of the forces to three significant figures. Separate your answers with a comma.

View Available Hint$($s$)$

$$

Part E $-$ The Sense of the Forces

State if the members considered in part D are in tension or compression.

Complete each sentence by dragging the appropriate word into the blank. The words can be used more than once.

$$

Submif

Previous Answers

Correct

Part F$-$The Forces in the Members at Joint $B$

Having found $F_{CD}$ in the analysis of joint $C$ and $F_{DB}$ in the analysis of joint $D,$ there are now only two unknown forces acting on joint $B.$ Determine the two unknown forces on joint $B.$ Express the magnitudes of the forces to three significant figures. Separate your answers with a comma.

View Avallable Hint$($s$)$

$lb,lb$

$$

Part G $-$ The Sense of the Forces

State if the members considered in part $F$ are in tension or compression.

Complete each sentence by dragging the appropriate word into the blank. The words can be used more than once.

$$

Holp

Raset

Member $BA$ is in tension $$

tension

Member $BE$ is in $$

$$ Provious Answers

Correct
