Learning Outcomes

Use TinkerCAD to develop an Arduino sketch.

Create documentation using flow chart.

Steps

Start the TinkerCAD. Note: Other programming editors like Arduino IDE are also acceptable.

Learn from the instructions from references $1$ and $2($in Reference section$)$ about creating flow charts using Microsoft

Visio $($online$).$ You may use other online software $($like

draw.io$)$ to draw the flow chart. Different flowchart symbols and

their meanings are shown in the reference $3.$

Create a flow chart that will perform the following task.

a$.$ Create an array containing numbers from $1$ to $50.$ Use the following line of code:

int nums $[]=\{1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,17,18,$

$19,20,21,22,23,24,25,26,27,28,29,30,31,32,33,34,35,36,37,$

$38,39,40,41,42,43,44,45,46,47,48,49,50\}$;

b$.$ Initialize a variable called $i$ to zero.

c$.$ If $i$ is less than the length of nums, then for each element nums $[i]$ in the array nums,

check if nums $[$i$]$ is divisible by $3$

if no$,$ print nums $[$i$]$ on the serial monitor

add $1$ to $i$

Notes on drawing the flow chart:

a$.$ The connecting lines should be arcs, not straight lines.

b$.$ The background color of the shapes should be white.

c$.$ The fonts in the symbols should be Calibri size $10.$

d$.$ Hint $1$: Create the shape, change its fill and fonts, then duplicate if necessary.

e$.$ Hint $2$: The number of symbols in the answer are:

Start$/$End x $2,$ Process x $3,$ Decision x $2,$ Document $1($for printing on serial monitor$),$ Connectors $9$

f$.$ Hint $3$: Try to arrange all the symbols in a vertical manner with Start at the top, and End at the bottom.

Write a sketch to perform the above task.

Notes:

a$.$ You must use the "while" keyword, not the "for" keyword.

b$.$ You should insert the following comments.

First comment should be $"$# Student Name & ID: CHAN Tai Man John $18012345$S$"$

Insert five other comments to explain your code at the right places.

The output should look similar to the screen below.

please give me The flowchart

and the source code

Explanation of the flowchart
