Question: please solve all parts thank you given attached below given: angle 1 - 2 - 3 : 1 7 0 - 0 6 - 1

please solve all parts thank you
given attached below
given:
angle 1-2-3: 170-06-15
angle:2-3-4: 41-07-20
angle 3-4-5=173-09-45
angle 4-5-1=135-01-04
angle 5-1-2=20-34-4
distance
given:
angle 1-2-3: 329.700
angle:2-3-4: 210.250
angle 3-4-5: 279.330
angle 4-5-1: 283.400
angle 5-1-2: 433.030
C. Complete a Compass Rule Adjustment for your traverse data. You should use the average values for the angles and the distances. Use the methodology from the lecture slides and the following guidelines:
i. All distances and coordinates should be shown to the nearest FOUR (4) decimal places
ii. All Angles and Azimuths should be shown to the nearest second of arc.
iii. The chart used in HW6(or a similar one you generate in excel) should be used. If you use the chart from HW 6, it must be filled in by hand, in
pencil, and all numbers must be legible. The blank chart is available on Brightspace for printing.
iv. The angular error should be evenly distributed to each angle.
v. The Linear Error of Closure should be shown to 4 decimal places.
vi. The denominator in the Representative Fraction should be shown to the nearest whole unit, for example: \(1/14,234\) NOT: \(1/14,234.4567\).
vii. The starting azimuth for the line from Point 1 to Point 2 should be \(260^{\circ}\)\(00^{\prime}00^{\prime \prime}\).
Calculations submitted using a starting azimuth different than the one required will be returned with a grade of zero.
viii. Along with the completed chart and including the summations as shown on the sample traverse used in lecture, submit the following calculations and/or representative calculations using engineering paper using the homework guidelines:
a. The determination of the angular error of closure
b. The determination of the amount of error to be diatributed to each angle
c. The calculation for ALL azimuths from your angles, including the check calculation using Angle 1. There should be a separate sketch for each azimuth calculation
d. The calculation of the unadjusted latitude and departure for line \(1-2\), only. This should include a sketch;
e. The calculation of the Linear Error of Closure
f. The calculation of the Representative Fraction
g. The calculation of the adjustment in north and adjustment in east for line 1-2 only.
h. The calculation of the adjusted latitude and departure of line 1-2, only.
i. The determination of the coordinates of Point 2
j. The determination of the balanced (final adjusted) Azimuth and Distance between Point 1 and Point 2.
please solve all parts thank you given attached
