Problem 3: Write a script that takes the length of three sides as inputs and determines if the sides can form a triangle. If the sides can form a triangle, the function determines the type of the triangle (if all sides are equal - equilateral, if two sides are equal - isosceles, or if no sides are equal - scalene). Hint: the triangle inequality states that for any triangle, the sum of the lengths of any two sides must be greater than or equal to the length of the remaining side. In other words, a triangle is defined when the sum of all three sides minus the max side is greater than or equal to the max side. 4. Given the following circuit diagram, what is the value output when the inputs are A = 1, B = 0, C = 1, D = 1, E = 0 (don't miss the two circles in the circuit)? (1 point) B Output D E 5. Draw the circuit diagram for the following Boolean expression (2 points) (NOT ( AND C)) AND (D AND (COR (NOT a))) 6. Given the following truth table, write a corresponding Boolean expression and then draw the circuit. (2 points) a b c out 0 0 0 0 0 0 0 0 1 0 0 1000 1 1 0 0 1 1 1 1
