Question: Problem 4 2 . The static deflection at the center of the steel shaft in Fig. 3 - 5 3 is equal to 0 .

Problem 42. The static deflection at the center of the steel shaft in Fig. 3-53 is equal to 0.35 mm . Find
the value of the critical speed. Shaft is steel.
Ans. n_(cr)=1810rpm.
Figure 3-53 Problem 42.
Problem 4 2 . The static deflection at the center
