Question 11 (4 points) Determine if this transistor circuit will function correctly (i.e. turn on the load when the switch closes) or not: The circuit is correct The circuit is NOT correct Question 12 (4 points) Determine if this transistor circuit will function correctly (i.e. turn on the load when the switch closes) or not: The circuit is correct The circuit is NOT correct Question 13 (4 points) Determine if this transistor circuit will function correctly (i.e. turn on the load when the switch closes) or not: The circuit is correct The circuit is NOT correct Question 14 (4 points) In the following circuit, the light bulb will energize when the pushbutton switch is actuated. Assume that the supply voltage in each case is somewhere between 5 and 30 volts DC (with lamps and resistors appropriately sized): + Determine if the circuit is properly designed. Either it will function perfectly, or function only once or twice before their transistors fail. The circuit is properly designed The circuit is NOT properly designed Question 15 (4 points) In the following circuit, the light bulb will energize when the pushbutton switch is actuated. Assume that the supply voltage in each case is somewhere between 5 and 30 volts DC (with lamps and resistors appropriately sized): Determine if the circuit is properly designed. Either it will function perfectly, or function only once or twice before their transistors fail. The circuit is properly designed The circuit is NOT properly designed
