Question: Short answer: For the structural plan shown below... A ) calculate tributary area for beam B 1 B ) assume the floor system must support

Short answer: For the structural plan shown below...
A) calculate tributary area for beam B1
B)assume the floor system must support its own weight of 100psf and a live load of 150 psf. What is the uniform load (lb/ft) applied to beam B1 on the second floor?
C) if the roof live load is 50 psf, the floor live load is 150 psf and the dead load for both is 100 psf, what is the column load for column B3 at the top floor?
PLEASE SHOW ALL WORK
Short answer: For the structural plan shown

Step by Step Solution

There are 3 Steps involved in it

1 Expert Approved Answer
Step: 1 Unlock blur-text-image
Question Has Been Solved by an Expert!

Get step-by-step solutions from verified subject matter experts

Step: 2 Unlock
Step: 3 Unlock
