Steps for

Assignment $7$

MCH$2310$ Strength of Materials I

Distributed Nov $22,2024$

Due November $29,20248$:$30$ am $-$ hardcopy submission

For each question, calculate the reactions and draw the shear and bending moment diagrams. Ensure all the drawings are to an appropriate reasonable scale and shown all required informations per class instructions. Show Horizontal scale for beam length, Vertical scale for shear, Vertical scale for moment

$2.$ Question Use table for Length and $"a"$ dimension and $P$ load. Use $kN$&$m$ for $-...$:$-$

For each question show:

Sign convention, Intermediate steps and units in each step, Equilibrium Equations

Free Body Diagrams of reactions with appropriate subscripts

Calculations of areas for moments showing all units

All work to be completed in engineering Format. Do not draw on the back gridline side of the engineering format paper. Clearly state all scales using appropriate round number values Assignment to be stapled or paper clipped.

Stack Loading diagram, shear diagram and moment diagram on one page vertically $($aligned$)$ with all required dimensions per class instructions

All diagrams to be drawn with a straight edge to scale

No answers to be boxed. Neatness, drawing scale, and clarity of calculations value $=50\%$ of assignment Late submissions past $8$:$30$am will receive an immediate $20\%$ penalty. $20\%$ penalty per day late applies

Value for que $1$ is L$=8\mathrm{.}1$m and W$=4\mathrm{.}60$kn$/$m and for que $2$ is L$=10\mathrm{.}8$m$,$ a$=1\mathrm{.}90$m and p$=57$kn
