Question: Three forces act on the bracket as shown in ( Figure 1 ) . The resultant force is directed along the positive a ' axis

Three forces act on the bracket as shown in (Figure 1). The resultant force is directed along the positive a' axis and has a magnitude of 7.4kN
Part A
Determine the magnitude of F
Express your answer to three significant figures and include the appropriate units.
F=
Part B
Determine the direction of F
Express your answer in degrees to three significant figures.
Provide Feedback
Three forces act on the bracket as shown in (

Step by Step Solution

There are 3 Steps involved in it

1 Expert Approved Answer
Step: 1 Unlock blur-text-image
Question Has Been Solved by an Expert!

Get step-by-step solutions from verified subject matter experts

Step: 2 Unlock
Step: 3 Unlock
