Question: 1 0 . In the figure below, the two rectangles ( and their parts ) are parallel and 'overlapping'. Determine the shape factor (

10. In the figure below, the two rectangles (and their parts) are parallel and 'overlapping'. Determine the shape factor \( F_{1 a-2}\), where surface 2 is the union of \(2 a \) and \(2 b \). The result should use shape factors only for parallel overlapping rectangles.
1 0 . In the figure below, the two rectangles (
