Question: A 1 0 - ft boom is acted upon by the 9 3 0 - l b force as shown in the figure. Determine the

A 10-ft boom is acted upon by the 930-lb force as shown in the figure.
Determine the tension in each cable and the reaction at the ball-and-socket joint at A.
The tension in cable BD is 1218.56 lb.
The tension in cable BE is lb.
The reaction at A is (1328.22lb)i+(-620lb)j.(Include a minus sign if necessary.)
My answers are wrong, please walk me through a step by step
A 1 0 - ft boom is acted upon by the 9 3 0 - l b

Step by Step Solution

There are 3 Steps involved in it
