. A distillation column with a total condenser is using open steam heating to separate ethanol from

water. Feed is 30 weights % ethanol and is at 20 oC. Distillate is a saturated liquid of 80 wt.%

ethanol. External reflux ratio is 1.15 times (L0/D) min. Bottom is 5 wt. % ethanol. Input steam is pure

water and is a saturated vapor. Pressure is 1 kg/cm2. Equilibrium data is given in Figure 2-4

(a) Find (L0/D) min and L0/D.

(b) Plot D and Plot B

(c) Use the Ponchon-Savarit analysis to determine the number of equilibrium stages and find

the optimum feed stage

600 600 500 Dertinez CM 500 traz Line tot waterpolenta . Erumarius composition 400 400 Enthalpy, kcal/kg. 300 300 902 gara ex && 200 79.5" 805 Isothermal ti yine 60C 89 882 84" 83 783 79- 78 4765C 78" 200 Anotropic Composition 100 100 Sboiling Line /kg/cm 100 800 60 40 202 OP Water day Zawia o Fred Line Solid Ice OC -100 J-100 gi 02 ds da ds db d7 0.8 d9 Concentration of Alcohol, Weight Fraction grybu
