Question: A simple beam ABC with a sliding support at A and a roller support at B is subjected to a concentrated force P = 7

A simple beam ABC with a sliding support at A and a roller support at B is subjected to a concentrated force P=750lb and a linearly distributed force with maximum intensity q0=120lbin as shown the figure, which also include the cross-section of the beam and its dimensions.
Determine:
a. The centroid location (from the bottom of the I-beam)
b. The moment of inertia about z-axis of the cross-section.
c. The maximum shear stress in the beam.
A simple beam ABC with a sliding support at A and

Step by Step Solution

There are 3 Steps involved in it
