CE $112-$Fall $24$

Final Exam

Name:

Question $(2)$: $1500$

For the beam and loading shown; determine:

a$)$ The maximum value of the shearing force and bending moment in the beam.

b$)$ The maximum shear stress in the cross section.

c$)$ The shear stress and normal stress at points $"a,b$ and $c".$

Point $"$b$"$ at the intersection of the flange and the web.

$7504=3000$
