Question: Chapter Three Part One Problems Question #1 - /18 marks A network consists of the activities in the following list. Times are given in weeks.

Chapter Three Part One Problems Question #1 - /18 marks A network consists of the activities in the following list. Times are given in weeks. Preceding Produchy Produs divide Activity A B D E F A A, B D Duration 8 3 7 3 4 6 a. Draw the AON network diagram. (3 marks for attempting the diagram, 1 mark for correct diagram) b. Calculate the ES, EF, LS, LF, and Slack for each activity. (6 marks for showing calculations for each, 4 marks for correct answers) c. What is project completion time? (3 marks for showing calculations, I mark for correct answer) Question #2 - /18 marks Draw the AOA (3 marks for attempting diagram, 1 mark for correct diagram) and AON (3 marks for attempting diagram, 1 mark for correct diagram) networks for the following project and calculate the minimum project duration (6 marks for showing calculations for each, 4 marks for correct answers). Activity Immediate Predecessors A B D E Duration (days) 10 8 2 4 5 A B, C, D
