Question: Consider the beam shown in ( Figure 1 ) . Take w = 3 k i p f t . Follow the sign convention. Correct

Consider the beam shown in (Figure 1). Take w=3kipft. Follow the sign convention.
Correct
Part D
Determine the normal force at point D.
Express your answer in kilopounds to three significant figures.
ND=0kip
Submit
Previous Answers
Correct
Part E
Determine the shear force at point D.
Express your answer in kilopounds to three significant figures.
Submit
Previous Answers
Correct
Correct answer is shown. Your answer -3.7 kip was either rounded differently or used a different number of significant figure:
Part F
Determine the moment at point D.
Express your answer in kilopound-feet to three significant figures.
MD=
kip *ft
Previous Answers
Request Answer
