Question: Consider the following transfer function for a circuit ( not shown ) . It has two corner frequencies. Show your work and provide your final
Consider the following transfer function for a circuit not shown It has two corner frequencies. Show your work and provide your final answers in the provided spaces.
a Describe the behavior of the magnitude of the transfer function, below the first corner frequency on a linear scale.
Answer:
b What is below the first corner frequency on a dB scale?
Answer:
c Describe the behavior of the magnitude of the transfer function, between the first and second corner frequencies on a linear scale.
Answer:
d Describe the behavior of between the first and second corner frequencies on a dB scale.
Answer:
e Describe the behavior of the magnitude of the transfer function, above the second corner frequency on a linear scale.
