Question: Explain this to me please. Assignment 15.3 Using JK flip-flops, design a divide-by-5 counter that follows the binary sequence 0-1-2-3-4-0 Assignment 15.4 Using JK flip-flops,

Explain this to me please. Explain this to me please. Assignment 15.3 Using JK flip-flops, design

Assignment 15.3 Using JK flip-flops, design a divide-by-5 counter that follows the binary sequence 0-1-2-3-4-0 Assignment 15.4 Using JK flip-flops, design an up/down counter that follows the binary sequence 0-1-2-3-4-0 for up and 0-4-3-2- 1-0 for down
