For a circular curve transition system, the deflection angle at the Point of intersection is $6{33}^{\text{'}}{00\mathrm{.}0}^{\text{'}\text{'}}$ and the radius is $7590m.$

a$)$ What is the Length of Curve?

b$)$ What is the distance from the Point of Intersection to the Mid$-$Point of the Curve?

c$)$ What is the straight$-$line distance from the Beginning of Curve to the End of Curve?

d$)$ What is the straight$-$line distance from the Beginning of Curve to the Point of Intersection?

e$)$ What is the straight$-$line distance from the Mid point of the Curve of Curve to mid point of the Long Chord?

$\backslash$table$[[$a$),867\mathrm{.}682,$m $(3$ decimal places$)],[$b$),12\mathrm{.}416,$m $(3$ decimal places$)],[$c$),867\mathrm{.}209,$m $(3$ decimal places$)],[$d$),$Blank $4,$m $(3$ decimal places$)],[$e$),$Blank $5,$m $(3$ decimal places$)]]$

Blank $1867\mathrm{.}682$
