L'ssignment $3[30$ Marks$]$

a$.$ Fig. Q$1$ shows an sometric projection of a solid object; the arrow indicates the direction

of the view from the front. Draw the following views in First Angle Orthographic

Projection.

i$)$ Front view

$[8$ Marks$]$

ii$)$ Top View

$[6$ Marks$]$

iii$)$ Side view from the Lefl hand side

Insert six principal dirnersions.

$[4$ Marks$]$

Include a sutable tite block and the projection symbol according to ISO conventions.

All dimensions are in millimettres.$$
