Database KatrinaFennellDB should already be created.

1. Write SQL queries for each of the tasks using MS SQL SERVER in the Virtual Lab.
2. Follow the underscore convention when naming your database schema, entities and attributes.
3. Save your work as an SQL script name your script 11056210_assignment2.sql. (Word document is acceptable as well, make sure you are submitting the same statement you used to create your tables in the virtual lab.)
4. For all tasks, use the Your Database Schema that you created. KatrinaFennellDB. I will check both your virtual database in the virtual lab and your submission on D2L

Consider the relational database schema diagram below. It consists of 3 entities movies, actors, and locations.

Because movies and actors have a many-to-many relationship and movies and locations have a many-to-many relationship, your schema would also have 2 junction tables movies_actors and movies_locations. Each tables logical structure is described below:

movies

Field name	Primary Key	Data type	Is null?	Is Identity?
movie_id	Yes	INT	no	yes
title	No	VARCHAR(200)	no	no
release_date	No	DATETIME	no	no
plot_description	No	VARCHAR(4000)	no	no

actors

Field name	Primary Key	Data type	Is null?	Is Identity
actor_id	Yes	INT	no	yes
first_name	No	VARCHAR(100)	no	no
last_name	No	VARCHAR(100)	no	no
birth_date	No	DATETIME	no	no
biography	No	VARCHAR(1000)	no	no

locations

Field name	Primary Key	Data type	Is null?	Is Identity?
location_id	Yes	INT	no	yes
location_name	No	VARCHAR(100)	no	no
street_address	No	VARCHAR(150)	no	no
city	No	VARCHAR(100)	no	no
state	No	CHAR(2)	no	no
zip	No	VARCHAR(5)	no	no

movies_actors

Field name	Primary Key	Data type	Is null?	Is Identity
movie_id	No	INT	no	no
actor_id	No	INT	no	no

movies_locations

Field name	Primary Key	Data type	Is null?	Is Identity?
movie_id	No	INT	no	no
location_id	No	INT	no	no

Task 1: In database [KatrinaFennellDB], create the following entity tables:

1. movies
2. actors
3. locations

Each tables Creation Statement should correspond to the descriptions provided in this assignment. Use CREATE TABLE statement.

Task 2: In your database, create the following junction tables:

1. movies_actors
2. movies_locations

Use CREATE TABLE statement to create junction tables. Make sure to create appropriate foreign keys each table will have two foreign keys.

Task 3: For each entity table, insert at least 3 rows using INSERT statement:

1. At least 2 movies in the movies table
2. At least 2 actors in the actors table
3. At least 2 locations in the locations table

You can make up your own data for the INSERT statements.

Task 4: For each junction table, create at least 2 relationships (insert at least two rows of appropriate IDs).

Task 5: Write a SELECT statement to display all actors

Task 6: Write a SELECT statement to display location name, street address and city.

movies actors movie_has_actors movie has locations locations
