Question: Problem 2.(10 points. ) Below is found an RC circuit. The switch is initially held in position b, position a for a long time. Then,

Problem 2.(10 points. ) Below is found an RC circuit. The

Problem 2.(10 points. ) Below is found an RC circuit. The switch is initially held in position b, position a for a long time. Then, it is moved to position b. 500ms after switching to 120V W 50000 20 MF 5000 (a) (4pt) What is now the potential difference across the 50000 resistor? (b) (4pt) How much power is now being supplied by the capacitor, to the circuit? (c) (2pt) How much energy has been dissipated by the 5000 0 resistor? (Hint: recall that Power = de = 12 R)
