Question: Problem 3 The analog input range of a 4 - bit ADC is from 0 to 1 [ V ] . The input is 0

Problem 3
The analog input range of a 4-bit ADC is from 0 to 1[V]. The input is 0.56[V], how much is the output?
0.56>12v=>1.
0.5612+14=0.75
0.5612+14+-18=4+2-18=58=0.625
0.5612+14-18-116=8+4-2-116=6916=0.3625
Problem 3 The analog input range of a 4 - bit ADC

Step by Step Solution

There are 3 Steps involved in it

1 Expert Approved Answer
Step: 1 Unlock blur-text-image
Question Has Been Solved by an Expert!

Get step-by-step solutions from verified subject matter experts

Step: 2 Unlock
Step: 3 Unlock
