Problem No$.2(40$ points$)$

Find the reactions for the beam shown below and plot the SFD and BMD in provided space. Write your reactions at indicated spaces $($remember magnitude and direction$).$ Parameters are $a=12-ft,b=20-ft$ and $P=30-$kip acting at $C.$ Neglect the self$-$weight of the beam. Assume El is constant.

Reactions

$A_y=,B_y=$

$B_x=0,M_B=$
