Question: Q 5 . points ] Consider the beam cross - section and the direction of moment applied as shown below. ( a ) Locate the

Q5. points] Consider the beam cross-section and the direction of moment applied as shown below.
(a) Locate the neutral axis of the beam cross-section (y-coordinate from the bottom of the section)
(b) What is the area moment of inertia of the cross-section with respect to the neutral axis?
(c) If the beam is made of material having an allowable (tensile or compressive) stress values of allow=150 MPa , determine the maximum moment M that can be applied to the beam.
