Question: Question 1 4 . Two separate cables are attached to a beam, as shown in the figure below. The mass of the uniform beam is

Question 14. Two separate cables are attached to a beam, as shown in the figure below. The mass of the uniform beam is 100 kg and the mass of the hanging block is 500 kg . Find a) the tension in the cable attaghed to the floor and b) the reaction force at the pivot.
