Question: Replace the force and couple moment system by an equivalent resultant force ( Figure 1 ) . Assume F 1 = 2 0 l b

Replace the force and couple moment system by an equivalent resultant force (Figure 1).
Assume F1=20lb.
Determine the magnitude of the equivalent resultant force.
Express your answer in pounds to three significant figures.
Part B
Determine the direction of the equivalent resultant force.
Express your answer in degrees to three significant figures.
Figure
Part C
Specify its coordinate point of application (0,y) on the y axis,
Express your answer in feet to three significant figures.
Replace the force and couple moment system by an

Step by Step Solution

There are 3 Steps involved in it

1 Expert Approved Answer
