Question: Replace the loading by an equivalent single resultant force ( Figure 1 ) . Assume F 1 = 1 4 0 N , F 2

Replace the loading by an equivalent single resultant force (Figure 1). Assume
F1=140N,F2=410N, and F3=520N.
Part A
Determine the resultant force.
Express your answer to three significant figures and include the appropriate units. Assume the positive direction is upward.
Request Answer
Part B
Specify the x and y coordinates of its line of action.
Express your answers in meters to three significant figures separated by a comma.
x,y=
Request Answer
Provide Feedback
Replace the loading by an equivalent single

Step by Step Solution

There are 3 Steps involved in it

1 Expert Approved Answer
