Question: SITUATION 1 . A 1 2 . 5 c m diameter Venturi meter is installed on a pipe 2 5 c m in diameter. Determine

SITUATION 1. A 12.5cm diameter Venturi meter is installed on a pipe 25cm in diameter. Determine
the discharge that would be passing through the meter when the double column differential mercury
gauge connected to it shows a difference of 20cm. It is found in a test that the total water passing in
the meter is 3500L for a period of 45s.
Determine the meter coefficient.
0.87
0.61
0.94
0.79
SITUATION 1 . A 1 2 . 5 c m diameter Venturi

Step by Step Solution

There are 3 Steps involved in it

1 Expert Approved Answer
Step: 1 Unlock blur-text-image
Question Has Been Solved by an Expert!

Get step-by-step solutions from verified subject matter experts

Step: 2 Unlock
Step: 3 Unlock
