The frame structure shown in the figure has fixed support at A and pin support at D $.$ When $w_o=3\mathrm{.}3$k$/$ft and $20-k$ force is applied to member $AB,$ determine reactive forces at supports A and $D.A$ is a fixed support and $B$ and $C$ are pin joints. Member $CD$ is a quarter circle.
