ASAP PLEASE

BJT AMPLIFIER OBJECTIVE: TO USE BJT AS AN AMPLIFIER SINGLE STAGE AND DOUBLE STAGE. EQUIPMENT USED: MULTISIM SOFTWARE, BJT TRANSISTOR ( 2N3904), R1 = 15K, R2 = 4.7K, RC = 2.2K, RE = 16 Ohm CS = 10UF, CB = 20UF, VCC = 20V, AND VS = 4mVpk, and F = 1KH. PROCEDURE: Make a single stage amplifier using voltage-divider biasing using above components. Then modify the circuit for double stage amplifier. Adjust the volt meter scale so that you can see the amplified signal at the output of second stage. In the diagram the amplifier is single stage. And the scale of scope is adjusted as shown below. CH1 = 2mV (VERTICAL SCALE) CH2 = 200mV(VERTICAL SCALE) HORIZONTAL SCALE WHICH IS TIME BASE = 500u sec. BJT AMPLIFIER OBJECTIVE: TO USE BJT AS AN AMPLIFIER SINGLE STAGE AND DOUBLE STAGE. EQUIPMENT USED: MULTISIM SOFTWARE, BJT TRANSISTOR ( 2N3904), R1 = 15K, R2 = 4.7K, RC = 2.2K, RE = 16 Ohm CS = 10UF, CB = 20UF, VCC = 20V, AND VS = 4mVpk, and F = 1KH. PROCEDURE: Make a single stage amplifier using voltage-divider biasing using above components. Then modify the circuit for double stage amplifier. Adjust the volt meter scale so that you can see the amplified signal at the output of second stage. In the diagram the amplifier is single stage. And the scale of scope is adjusted as shown below. CH1 = 2mV (VERTICAL SCALE) CH2 = 200mV(VERTICAL SCALE) HORIZONTAL SCALE WHICH IS TIME BASE = 500u sec
