Assignment$-2/$Project $(10\%)$

Consider the cantilever retaining wall with the cross$-$section shown in the

adjacent Figure, which retains a $2$ m depth of soil having the groundwater table

at $-1\mathrm{.}0$ m level.

Design Data and Parameters:

Soil Bearing Capacity, $q_{\text{a}\text{n}\text{d}}=105$kPa

Coefficient of Soil Friction, $$:$30$

Unit Weight of Soil, $y_s$:$17\mathrm{.}5k\frac{N}{m^3}$

Unit Weight of Water, $y_w$:$9\mathrm{.}81k\frac{N}{m^3}$

Unit Weight of Concrete, $Y_c$:$2\mathrm{.}65k\frac{N}{m^3}$

Surcharge, $$:$11\mathrm{.}5k\frac{N}{m^2}$

Ground Water Level: $-1$ m from $0\mathrm{.}00$ level

Height of Surcharge, h: $0\mathrm{.}8$ m

Height of Wall: $2\mathrm{.}0$ m

f$\text{'}$s: $32$ Mga

fx: $460$ Mga

concrete cover. $75$ mm

a$)$ Design the retaining wall with respect to stability in terms of overturning moment,

sliding, and slipping. Also check the wall thickness against shear, bearing pressure

under the footing, and check the required length of the retaining wall base. provide the

reinforcement design.

b$)$ Provide detailed drawings of reinforcement of the retaining wall based on your

structural design.

c$)$ Discuss and conclude your design work.
