Name

St #

Design the rectangular combined footing shown in the figure, using the data given below.

The design should include:

$($a$)$ Dimensioning $L^{\text{'}}($extended $L)$ and $B$ to obtain uniform base pressure. $($Show the extended footing

len $\{$:${?}_6*h).(15\%)$

$($b$)$ Determination of effective depth, $d$ using wide$-$beam shear check only. $(15\%)$

$($c$)$ Determination of the maximum positive $(+M$ and maximum negative $(-$M$)$ moments. $(10\%)$

Draw the SFD and BMD in the space provided below the figure.

$L$

B

Span $=5\mathrm{.}65m$
