Q$.2($b$).$

Section

A continuous beam ABC has a uniform$-$cross with three supports and a total length of the beam of $10$ m $.$ Supports A$,$ B and C are at the same level and is loaded as shown in Fig. Q$.2($b$)$ below.

Using the Three Moment Theorem method, determine the following:

$($i$)$ Moments over the beam.

$($iit Draw the bending moment diagram.

$($iii$)$ Calculate reactions at supports and

$($iv$)$ Draw the shear force diagram.
