Save Answer Question 31 2 points A wireless network administrator is using 3 access points (APs) to cover an area. At some locations, all 3 APs may be in range of a single wireless device. What wireless channels should be assigned to the APs? (Hint: Pick 3 different channels.) a. 1 b. 10 C. 6 d. 8 e. 9 f. 11 8.4 h.5 i. 2 O j. 3 k. 7 Question 32 The figure below shows a wired network with IP and MAC addresses assigned for each NIC. 21 2 H src MAC dst MAC src IP dst IP 1 src MAC dst MAC src IP dst IP Server EX Client 152.19.230.7 0a:e0:eb:27:30:c6 152.19.230.200 12:dd:b1:03:53:01 Router 128.82.5.254 32:00:17:17:40:03 128.82.5.4 08:e0:eb:27:05 The client sends a packet to the server (labels 1 and 2). Indicate the source and destination IP and MAC addresses for label 1. source MAC destination MAC source IP destination IP Question 33 How many bits are in 2 KB (kilobytes)? Question 34 2 points Save A Consider the network in the figure below. Host A Host B Host A and Host B are connected by a single 4 Mbps (Megabits per second) link that has a propagation delay of 25 ms (milliseconds). Host A sends a 3000-byte packet starting at time t=0. At what time (in ms) is the packet fully received by Host B (i.e., what is the end-to-end delay)? Question 35 2 points Save Answe A host inside the odu.edu domain needs to determine the IP address of www.cs.unc.edu. Assume that the local authoritative NS for the odu.edu domain has the following cache entries: NS NS NS f.root-servers.net. 1.edu-servers.net. ns.unc.edu. 192.5.5.241 192.41.162.30 152.2.21.1 edu unc.edu f.root-servers.net. 1.edu-servers.net. ns.unc.edu. A A What is the first nameserver that the local authoritative server contacts? a. none of the above b.f.root-servers.net. O c. I.edu-servers.net. d. ns.unc.edu
